Equipment performance and features:
This machine is suitable for round bottle enclosed and fixed-point automatic labeling in various industries
Powered soft rubber roller three-roll servo-pinch positioning to ensure labeling accuracy and production line efficiency
Dual operation interface in Chinese and English, and color recognition blocks, simple and easy to learn, a truly intelligent device
High power, ultra-small moment of inertia, large torque to send the bid motor, the sending speed can reach 45 meters/minute
8-dimensional space adjustment of the marker, multi-path adjustment of the bottle type, can be tilted at ±12°, and can be easily completed with taper bottle type labeling
Technical parameters:
380V 50Hz 3000W
Product model: | DDU-1603G |
Bidding speed: | 0.1-45 meters per minute adjustable |
Maximum diameter of label: | 350 mm |
Maximum label width: | 130 mm |
Minimum label width: | 15mm |
Working face height: | 900mm |
Maximum size of the quilt: | Thickness (diameter) ≤130mm |
Marking accuracy: | ±0.3 mm |
Use air pressure: | 3-5KG |
Overall machine size: | L2000*W1500*H1550mm |
The weight of the whole machine: | About 320 KG |
